Helvia SIGNUM series is a line of cables, connectors and adapters engineered and designed to meet the specifications required by contractors, system integrators and show industry professionals ranging from microphone cables to fire retardant, speaker and network cables, built with premium quality technologies and satisfying all the certifications required by the residential and commercial field.
S/UTP (braided shielding + unshielded twisted pairs)
Highly flexible with very robust TPE jacket
EtherSound up to 70m
RJ45 plug featuring Nylon protective housing and metal cable clamp holder
1.50 mt Length
Jacket diameter: 6.4 mm
AWG: 24
No. of inner conductors: 4 x 2 x 0.51 mm
Shielding factor: 90 % (Shielding Tin copper braided shielding with 128 x 0.10 mm Tin copper)
Conductor insulation HDPE
Temperature range: -40 °C / 85 °C
RJ45 plug: CAT5e, 150MHz, max. AWG26
